Description
Specifications
Power
- Input Voltage – 5V-12V DC
- Total Current Limit – 30A
- Current Per Output – 7.5A
Data
- Standard Outputs: 4
- Expanded Outputs: 8
- RGB Pixels/Output: 680
- RGBW Pixels/Output: 512
- sACN or Art-Net Universes: 16
Physical
- Fused Pixel Outputs: 4
- Output Connector: 4 Pin Advatek Male
- Ethernet Inputs: 1
- Air Vents: 2
- Length: 125mm Width x 75mm Height x 70mm
- Weight: 0.275kg
- Enclosure: Polycarbonate
- Mounting: Wall Mountable
- Operating Temperature: -40°C to +80°C
